Broadline IP65 Surface 1144mm

Surface Linear System

Key Features

Light Source

Tridonic LLE LED

Colour Temperature

3000K / 4000K

Mounting

Surface mounting

Application

Interior Ceiling

Housing

Extruded Aluminium

Enquire Build your product

Enquire

Build your product

1 / 4

Overview

Cat. No: S18622IPS

This IP65 version of the Broadline Surface Mounted allows for installation in exterior environments. Produced in high quality aluminium extruded profile, the Broadline IP65 Surface luminaire can be supplied in standard lengths, or custom cut to suit. Can be supplied with an alternative prismatic diffuser. Get in touch to discuss full customisation options.

Downloads

TECHNICAL OVERVIEW (PDF)	>
DRAWING (JPG)	>
PHOTOMETRY (LDT)	>
SOVEREIGN SURFACE & RECESSED BROCHURE (PDF)	>

Dimensions

Technical Details

Lamp:	Tridonic LLE LED Module
Lamp:	50,000 hours
CRI	>80
Wattage:	29W
Voltage:	240V
Class:	Class 1
Driver:	Integrated high efficiency
Cooling:	Passive heatsink
IP Rating	IP65
LED Warranty:	5 years

Housing Specifications

Housing Material	Extruded Aluminium
Finish	Powder Coated
Optics	Opal diffuser
Dimensions	L1144mm x H75mm x D50mm
Weight	5kg
Mounting	Surface mounting

Light Output Details

Length	Col. Temp	Wattage	Lumen Output	Sys Efficacy
584mm	3000K	15W	2350lm	161lm/W
584mm	4000K	15W	2470lm	169lm/W
1144mm	3000K	29W	4700lm	161lm/W
1144mm	4000K	29W	4940lm	169lm/W
1424mm	3000K	37W	5870lm	161lm/W
1424mm	4000K	37W	6170lm	169lm/W
1704mm	3000K	44W	7045lm	161lm/W
1704mm	4000K	44W	7410lm	169lm/W
