Broadline Surface 584mm
Surface Linear System
Light Source
Tridonic LLE LED
Colour Temperature
3000K / 4000K
Mounting
Surface mounting
Application
Interior Ceiling
Housing
Extruded Aluminium
1 / 4
Overview
Cat. No: S18620S
A beautifully elegant surface mounted linear system, designed around the latest high performance Tridonic LLE LED modules. Produced in high quality aluminium extruded profile, the Broadline Surface luminaire can be supplied in standard lengths, or custom cut to suit. Also available as individual lengths or joined via plug & socket connection to provide “continuous” runs as required.
Supplied with standard or blind end caps (illustrated opposite), as well as an alternative prismatic diffuser. Get in touch to discuss full customisation options, including custom shapes and angles.
.
Downloads
| TECHNICAL OVERVIEW (PDF) | > |
| DRAWING (JPG) | > |
| PHOTOMETRY (LDT) | > |
| SOVEREIGN SURFACE & RECESSED BROCHURE (PDF) | > |
Dimensions
Technical Details
| Lamp: | Tridonic LLE LED Module |
| Lamp: | 50,000 hours |
| CRI | >80 |
| Wattage: | 15W |
| Voltage: | 240V |
| Class: | Class 1 |
| Driver: | Integrated high efficiency |
| Cooling: | Passive heatsink |
| IP Rating | IP40 |
| LED Warranty: | 5 years |
Housing Specifications
| Housing Material | Extruded Aluminium |
| Finish | Powder Coated |
| Optics | Opal diffuser |
| Dimensions | L584mm x H75mm x D50mm |
| Weight | 2.5kg |
| Mounting | Surface mounting |
Light Output Details
| Length | Col. Temp | Wattage | Lumen Output | Sys Efficacy |
| 584mm | 3000K | 15W | 2350lm | 161lm/W |
| 584mm | 4000K | 15W | 2470lm | 169lm/W |
| 1144mm | 3000K | 29W | 4700lm | 161lm/W |
| 1144mm | 4000K | 29W | 4940lm | 169lm/W |
| 1424mm | 3000K | 37W | 5870lm | 161lm/W |
| 1424mm | 4000K | 37W | 6170lm | 169lm/W |
| 1704mm | 3000K | 44W | 7045lm | 161lm/W |
| 1704mm | 4000K | 44W | 7410lm | 169lm/W |
