Linear Nano ALN
Linear System
Light Source
9.6W/mtr LED tape
Colour Temperature
2700K / 3000K / 4000K
Mounting
Surface mounting
Application
Interior linear lighting
Housing
Extruded Aluminium
Overview
Cat no. ALN
The Sovereign Linear Nano is our thinnest profile, perfect for the most subtle of illumination. This surface-mounted system combines a quality aluminium profile with a 24V DC high CRI 90 LED tape, resulting in a system providing pinpoint high quality illumination. It is available with a choice of three different quality UV resistant, snap-in diffusers; frosted, semi-frosted and transparent. The fully frosted diffuser transforms the individual LEDs into a smooth, soft illumination.
Our range of drivers and dimmable options cater for all solutions; from simple on/off control to full DMX systems. Get in touch for a selection of Linear System options.
Downloads
| OVERVIEW (PDF) | > |
Dimensions
Technical Details
| Range Name: | Sovereign Linear Nano |
| Range No. | ALN |
| Colour Rendering: | CRI 90 |
| Profile material | Extruded Aluminium |
| Installation: | Surface mounted with clips |
| Accessories: | Supplied with End Caps |
Housing Specifications
| Housing Material | Extruded Aluminium |
| Finish | Anodised / Powder coated |
| Optics | Clear / frosted / semi-frosted |
| Dimensions | H9mm x W7.8mm |
| Weight | |
| Mounting | Surface mounting |
Light Output Details
| Col. Temp | Power | Lumen Output | LEDs/mtr |
| 2500-2700K | 9.6W | 700-750lm/mtr | 120 LEDs |
| 3000-3500K | 9.6W | 800-850lm/mtr | 120 LEDs |
| 4000-4500K | 9.6W | 850-900lm/mtr | 120 LEDs |
Build Your Product
Light Source
Length
Profile
Diffuser
Product code:
Product details:
