Nano Tini
Fine Jewellery Lighting
Light Source
LED
Colour Temperature
2700K / 3000K / 4000K
Mounting
Surface mounting
Application
Fine Jewellry Lighting
Housing
Aluminium
1 / 6
Overview
Very small (20×9 mm) and very powerful spot for showcases. It is the highest concentration of LED technology and miniaturization of the components, fully developed by DGA. It is the first product that uses the new nano lenses, ΓΈ 5mm.
NANO TINI is the ideal product for projects where the light source is required to be hidden. The new lenses are equipped with glare-resistant snoot and are available with three beam angles: 20Β°, 30Β°, 50Β°.
For more info, visit DGA.
Downloads
| Datasheet | > |
| Overview PDF | > |
| Photometry | > |
Technical Details
| Range Name | NANO TINI |
| Lamp Life | 50,000 hours |
| Driver | Remote |
| Wattage: | 1W - 2W |
| Output: | 50lm - 80llm |
| Protection Rating | IP40 |
| Protection Class | III |
| CRI | >80 |
Housing Specifications
| Housing Material | Aluminium / Brass |
| Finish | Anodised / Chrome plated |
| Optics | Opal PMMA |
| Dimensions | Γ9mm x 20mm |
| Weight | 10g |
| Mounting | Surface mounting |
