Monospot Gobo
Floodlight
Light Source
LED
Colour Temperature
3000K / 6500K
Mounting
Surface / Pole
Application
Gobo projection
Housing
Die-cast aluminium
1 / 4
Overview
Cat. No: M8905
For the Monospot series there is a gobo projector available with precise optics for sharpe-edged image projections. The optical system can accommodate gobos and colour filters simultaneously. With the help of a framer, the edges of the image can be defined and adapted to the size of the projection surface.The Monospot series thus offers many possibilities for imaginative illumination.
For more info, please visit Meyer.
Dimensions
Technical Details
| Range Name | Meyer Monospot Gobo |
| Cat No. | M8905 |
| Lamp: | LED |
| Power | 55W |
| Lamp Life: | 50,000 hours |
| Protection type: | IP65 |
| Protection Class: | Class 1 |
| Impact Resistance: | IK08 |
| CRI | >70 |
| Tilt Range: | 180º |
Housing Specifications
| Housing Material | Die-cast Aluminium |
| Finish | Powder Coated |
| Optics | Tempered anti-reflective glass |
| Dimensions | Ø215mm, width 390mm |
| Weight | 8KG |
| Mounting | Surface / Pole |
Light Output Details
| Focal Length |
Col Temp. | Wattage | Lumen Output |
| 45mm | 6500K | 55W | 1724lm |
| 45mm | 3000K | 55W | 1483lm |
| 63mm | 6500K | 55W | 1240lm |
| 63mm | 3000K | 55W | 1066lm |
| 85mm | 6500K | 55W | 1680lm |
| 85mm | 3000K | 55W | 1445m |
| 150mm | 6500K | 55W | 1795lm |
| 150mm | 3000K | 55W | 1544lm |
